Dissolved Oxygen Sensor DO Meter Water Measuring Instruments Water Quality Monitor Fluorescence Online Analyzer

Short Description:

These sensors utilize proprietary fluorescent-sensitive materials. They do not consume oxygen, are insensitive to water velocity, and require no electrolyte addition, significantly reducing maintenance requirements. They also feature a built-in temperature compensation module and support RS485 digital signal output. Their robust anti-interference capabilities and excellent long-term stability enable rapid integration into aquaculture and environmental water quality measurement and control systems.

Send email to us Download

Product Detail

Product Tags

Product Vedio

Product Features

1. Simultaneously measures temperature, dissolved oxygen, and saturation.
2. Based on the optical probe's fluorescence method, it requires no regular refilling and is maintenance-free.
3. Highly stable data and durable.Data stabilizes within 5-10 seconds after power-up, offering a fast response time.
4. Supports probe replacement, extending service life.
5. Configurable salinity and pressure compensation, suitable for use in seawater or high-altitude areas.

Product Applications

This series of fluorescent dissolved oxygen sensors are designed for aquaculture and environmental water quality monitoring. They can be used in seawater or high altitude areas.

Product Parameters

Measurement parameters
Product name	Optical Dissolved Oxygen Sensor
Measurement Principle	Fluorescence method
Measuring Range	0-50mg/L or 0-500% saturation
Accuracy	±5% or ±0.5mg/L (20mg/L) ±10% or ±1mg/L (>20mg/L)
Temperature Range and Accuracy	0-50°C/±0.5°C
Waterproof rating	IP68
Maximum depth	30 meters
Output Signal	RS-485, Modbus Protocol
Power Supply	0.1W. Recommended Power Supply: DC 5-24V.
Mounting method	G3/4 thread, immersion mount
Cable Length	5 meters (default), customizable
Fluorescent membrane head warranty	one year under normal use
Housing material	316L+ABS, PC.
Wireless transmission
Wireless transmission	LORA / LORAWAN(EU868MHZ,915MHZ), GPRS, 4G,WIFI
Provide cloud server and software
Software	1. The real time data can be seen in the software . 2. The alarm can be set according to your requirement. 3. The data can be download from the software.

FAQ

Q: How can I get the quotation?

A: You can send the inquiry on Alibaba or the below contact information, you will get the reply at once.

Q: What's the main characteristics of this sensor?

1. Active correction of dual optical paths, channels with high resolution, accuracy and wide wavelength range;

2. Monitoring and output, using UV-visible near-infrared measurement technology, supporting RS485 signal output;

3. Built-in parameter pre-calibration supports calibration, calibration of multiple water quality parameters;

4. Compact structure design, durable light source and cleaning mechanism, 10-year service life, high-pressure air cleaning and purge, easy maintenance;

5. Flexible installation, immersion type, suspension type, shore type, direct plug-in type, flow-through type.

Q:Could I get samples?

A:Yes,we have materials in stock to help you to get the samples as soon as we can.

Q: What’s the common power supply and signal output?

A: Common power supply and signal output is DC: 220V, RS485. The other demand can be custom made.

Q: How can I collect data?

A: You can use your own data logger or wireless transmission module if you have , we supply the RS485-Mudbus communication protocol.We can also supply the matched LORA/LORANWAN/GPRS/4G wireless module.

Q: Do you have the matched software?

A:Yes, we can supply the software , you can check the data in real time and download the data from the software, but it need use our data collector and host.

Q: What’s the standard cable length?

A: Its standard length is 5m. But it can be customized, MAX can be 1km.

Q: What's the lifetime of this Sensor?

A: Usually 1-2 years.

Q: May I know your warranty?

A: Yes, usually it’s 1 year.

Q:What’s the delivery time?

A: Usually, the goods will delivered be in 3-5 working days after receiving your payment. But it depends on your quantity.

Just send us an inquiry at the bottom or contact Marvin for more information, or get the latest catalog and competitive quotation.
