1.Intelligent Radar Monitoring for Dam Safety, Ecological Flow Compliance, and Flood Management
Honde Technology Co., Ltd.provides a complete intelligent monitoring solution for reservoir dams and ecological water discharge projects, integrating radar flow measurement, water level monitoring, rainfall monitoring, weather monitoring, displacement monitoring, and automatic alarm systems.
Complete Ecological Discharge Monitoring System
The monitoring system supports 24/7 continuous online monitoring for:
- Reservoir ecological discharge outlets
- Spillways
- Open channels
- Diversion tunnels
- Downstream river sections
- Flood discharge areas
The complete solution includes:
- 3-in-1 radar flow meters
- Radar water level sensors
- Radar surface velocity sensors
- Dam displacement sensors
- Stainless steel rain gauges
- 7-in-1 ultrasonic weather stations
- Audible and visual alarm systems
2.3-in-1 Radar Flow Meter for Reservoir Discharge Monitoring
Model: RD-RWFMS-01
The 3-in-1 radar flow meter integrates:
- Water level measurement
- Surface velocity monitoring
- Flow calculation
into one compact intelligent device.
Product Advantages
Non-Contact Radar Measurement
The radar sensor measures water level and flow velocity without touching the water surface, making it highly resistant to sediment, floating objects, and water contamination.
High Protection for Harsh Environments
With IP68 waterproof protection and built-in lightning and surge protection, the device can operate reliably in heavy rain, flood discharge, and severe outdoor conditions.
Easy Installation and Maintenance
Bluetooth 5.2 mobile debugging allows engineers to configure and maintain the device directly from a smartphone.
Real-Time Data Transmission
Supports RS485 Modbus communication for integration with SCADA and remote monitoring platforms.
Technical Specifications
- Velocity Range: 0.05 m/s ~ 40 m/s
- Velocity Accuracy: ±0.01 m/s
- Measuring Distance: Up to 65 m
- Distance Accuracy: ±1 mm
- Power Supply: 7-28VDC
- Protection Level: IP68
3.Dual Radar Flow Monitoring System for High Accuracy Applications
Model: RD-600S-1
The RD-600S adopts a dual radar architecture combining:
- 24GHz radar velocity measurement
- 60GHz radar water level measurement
to achieve highly accurate ecological discharge flow monitoring.
Ideal Applications
- Dam ecological release monitoring
- Spillway flow monitoring
- Irrigation channels
- Open channel flow measurement
- Culvert flow monitoring
Key Features
- Accurate flow calculation based on Doppler radar technology
- Suitable for trapezoidal, circular, and irregular channels
- Stable operation during high flow and flood discharge
- Non-contact measurement reduces maintenance costs
Technical Specifications
- Velocity Range: 0.03-20 m/s
- Velocity Accuracy: ±0.01 m/s
- Water Level Accuracy: ±2 mm
- Communication: RS485 / RS232 / 4-20mA
- Protection Level: IP68
4.Radar Water Level Monitoring for Reservoir Dams
Radar water level sensors are widely used in reservoir dams due to their excellent performance in humid and high-flow environments.
Main Advantages
- Millimeter-level measurement accuracy
- Strong anti-interference capability
- Stable operation in fog, rain, and water vapor
- Long service life with low power consumption
- Compact design for easy installation near gates and spillways
Available radar frequencies include:
- 24GHz radar
- 60GHz radar
- 80GHz high-frequency radar
Measurement ranges can be customized up to 80 meters.
5.Dam Safety Monitoring and Displacement Detection
Model: RD-DWD-01
The displacement monitoring sensor is designed for:
- Dam slope monitoring
- Structural deformation detection
- Geological movement warning
- Reservoir safety monitoring
Key Benefits
- Real-time online monitoring
- Early warning for structural movement
- Durable aluminum alloy construction
- Stainless steel cable for long-term outdoor use
- IP68 waterproof protection
Technical Specifications
- Measuring Range: 100 mm – 35000 mm
- Linear Accuracy: ±0.25% FS
- Repeatability: ±0.05% FS
- Output: RS485 / 4-20mA / Voltage
6.Rainfall and Weather Monitoring System
Monitoring Parameters
- Rainfall
- Wind speed
- Wind direction
- Temperature
- Humidity
- Atmospheric pressure
- Solar radiation
System Advantages
- 24/7 continuous operation
- Maintenance-free ultrasonic technology
- Compact integrated structure
- Long outdoor service life
- RS485 Modbus communication
7.Audible and Visual Warning System for Flood Discharge
Before flood discharge or ecological water release begins, the monitoring platform can automatically activate:
- High-power sirens
- Flashing warning lights
- Remote alarm notifications
This helps improve downstream safety and reduce accident risks.
8.Project Benefits
By deploying Honde’s intelligent reservoir monitoring solution, customers can achieve:
Accurate ecological discharge monitoring
Improved dam safety management
Reduced manual maintenance costs
Real-time remote monitoring
Better flood control efficiency
Reliable long-term outdoor operation
Smart early warning capability
The solution is suitable for:
- Reservoir dams
- Hydropower stations
- Irrigation systems
- Water conservancy projects
- River management projects
- Flood prevention systems
9.About Honde Technology
Honde Technology Co., Ltd. specializes in environmental monitoring and hydrological sensing solutions for global engineering projects.
Main products include:
- Radar hydrological sensors
- Water quality monitoring systems
- Weather stations
- IoT environmental monitoring equipment
- Smart agriculture sensors
OEM and ODM services are available for distributors and engineering contractors worldwide.
For more information, please visit:
Email: info@hondetech.com
Post time: May-13-2026
