RS485 Output Triaxial tilt sensor
Features
● Using Kalman filter algorithm, so that the equipment acquisition Angle value is accurate and stable.
● With a wide range of Angle measurement, the output signal linearity is good, can meet the vast majority of environment use.
● Special 485 circuit, standard ModBus-RTU communication protocol, communication address and baud rate can be set.
●5~30V DC wide voltage range power supply.
● It has the characteristics of wide measuring range, good alignment, easy to use, easy to install, and long transmission distance.
● Attitude high speed output
● Three level digital filter processor
●Six axis inclination: three axis gyroscope + three axis accelerometer
●Nine axis inclination: three axis gyroscope + three axis accelerometer + three axis magnetometer
● High precision range, reduce environmental changes caused by data error, static accuracy of 0.05°, dynamic accuracy of 0.1°
●ABS material shell high strength, impact resistance, anti-interference, reliable quality, durable; IP65 High protection level
●PG7 waterproof interface is resistant to oxidation, waterproof and moisture-proof, with good stability and high sensitivity
Send matched cloud server and software
Can use the LORA/ LORAWAN/ GPRS/ 4G/WIFI wireless data transmission.
It can be RS485 output with wireless module and matched server and software to see real time in PC end
Application
Widely used in industrial dip measurement and dangerous house monitoring, ancient building protection monitoring, bridge tower survey, tunnel monitoring, dam monitoring, weighing system tilt compensation, drilling tilt control and other industries, safe and reliable, beautiful appearance, convenient installation.
Product parameters
| Product name | Inclinometers Tilt Sensors |
| Dc power supply (default) | DC 5-30V |
| Maximum power consumption | 0.15 W or less |
| Operating temperature | To 40 ℃, 60 ℃ |
| Range | X-axis -180°~180° |
| Y-axis -90°~90° | |
| Z-axis -180°~180° | |
| Resolution | 0.01 ° |
| Typical accuracy | The static accuracy of X and Y axis is ±0.1°, and the dynamic accuracy is ±0.5° |
| Z-axis static accuracy ±0.5°, dynamic integration error | |
| Temperature drift | ± (0.5°~1°), (-40°C ~ +60°C) |
| Response time | < 1S |
| Protection class | IP65 |
| Default cable length | 60 cm, cable length can be customized according to the requirement |
| Overall dimension | 90*58*36mm |
| Output signal | RS485/0-5V/0-10V/4-20mA/Analog quantity |
FAQ
Q: What material is the product?
A: ABS material shell high strength, impact resistance, anti-interference, reliable quality, durable; IP65 High protection level
Q: What is the output signal of the product?
A: Digital signal output type: RS485/0-5V/0-10V/4-20mA/ analog.
Q: What is its power supply voltage?
A: DC 5-30V
Q: How do I collect data?
A: You can use your own data logger or wireless transmission module. If you have one, we provide RS485-Mudbus communication protocol. We can also provide matching LORA/LORANWAN/GPRS/4G wireless transmission modules.
Q: Do you have matching software?
A: Yes,We have matching cloud services and software, which is completely free. You can view and download data from the software in real time, but you need to use our data collector and host.
Q: Where can the product be applied?
A: Widely used in industrial dip measurement and dangerous house monitoring, ancient building protection monitoring, bridge tower survey, tunnel monitoring, dam monitoring, weighing system tilt compensation, drilling tilt control and other industries, safe and reliable, beautiful appearance, convenient installation.
Q: How can I get samples or place an order?
A: Yes, we have materials in stock, which can help you get samples as soon as possible. If you want to place an order, just click on the banner below and send us an inquiry.
Q: What is the delivery time?
A: Usually, the goods will be shipped within 1-3 working days after receiving your payment. But it depends on your quantity.
